Features
- Additional features protected against back-flow in domestic use (according to DIN EN 1717)
- Connection Eccentric coupling(s)
- Lever/Handle Temperature control handle, Flow control handle, Easy-Grip surface, Eco feature for water flow, Safety feature for water temperature
- Mechanical parts Thermostatic cartridge for automatic temperature control, Litter filter(s), Ceramic head part for flow control
- Advanced features Inner body made of DZR brass
- Color Chrome
- Temperature Limitation option for maximum temperature and flow-rate, Safety stop against scalding at 38°C, The housing of the fittings conducts minimal heat, Temperature preset fixable
Flow attributes
- Eco-flow at 3 bar 12.6 l/min
- Flow-rate at 3 bar 16.2 l/min
Technical properties
- Backflow prevention (EN1717) EB
- DN-size (nominal dimension) DN15
- Hot water supply max. +80°C
- Installation width 150 ± 15 mm
- Material Brass/Plastic
- Working pressure 1 - 10 bar
Regulations
- EN standard EN 1111
- Noise class I (ISO 3822)
+SP7150(2013)+SP7151(2013)+SP65140101+SP7160U-33.webp)
SP65140101 Shower faucet
Ask pricing from your local retailers.
| Spare parts | Code | Spare part guide | ||
| 01 |
|
Flow control handle |
|
|
| 02 |
|
Headpart, G1/2 |
|
|
| 03 |
|
Filter sealing, G3/4 |
|
|
| 04 |
|
Temperature control handle |
|
|
| 05 |
|
Thermostatic cartridge, 3.4 |
|
Download |
