07442203 | Kitchen faucet

ALESSI Swan by HANSA

EAN code
4057304005534
Active market areas
INT, DEU, AUT, BEL, NLD, FRA, CZE, SVK, ESP

Find local dealers

Features

  • Aerator Hidden aerator, Standard aerator
  • Connection Flexible inlet pipes
  • Lever/Handle Two operating levers/handles, Temperature control handle, Flow control handle
  • Mechanical parts Litter filter(s)
  • Spout Swivel spout
  • Color Chrome

Flow attributes

  • Flow-rate at 3 bar 12 l/min

Technical properties

  • Connection size G3/8
  • DN-size (nominal dimension) DN15
  • Hot water supply max. +80°C
  • Material Brass
  • Projection 181 mm
  • Working pressure 1 - 10 bar

SP07442203 Kitchen faucet

Ask pricing from your local retailers.

Spare parts Code Spare part guide
01
Aerator, STD M24x1 CC S
Aerator, STD M24x1 CC S
  • 59914143
02
Sealing kit for spout
Sealing kit for spout
  • 59914266
03
Cartridge
Cartridge
  • 59914503
04
Bearing ring
Bearing ring
  • 59914504
05
Limiter
Limiter
  • 59914506
06
Temperature control handle
Temperature control handle
  • 59914507
07
Flow control handle
Flow control handle
  • 59914508
08
Fixing set
Fixing set
  • 59914509
09
Supporting plate
Supporting plate
  • 59910008
10
Gasket, 8x14.3x2
Gasket, 8x14.3x2
  • 59914087
11
One-way valve with litter screen
One-way valve with litter screen
  • 59914086
12
Litter filters
Litter filters
  • 59914085
