HANSAVIVA
Designed to impress and give an elegant solution for any bathroom.
This rainshower system gives you a most comfortable and enjoyable shower experience every day. With focus on high performance while still have and eye on the aesthetics and details to secure an easy installation.
The handles are designed to be elegant while still providing a good grip for easy.
Our new developed magnectic shelf ”MagShelf” completes the design while covering the connection to the wall.
The large and flat head shower has a gentle spray that covers the whole body. Enjoy the even and strong water stream for the ultimate relaxation.
Our 3-spray handshower is easy to operate with a nice designed push button to easily change the water sprays.
Elegant design and total enjoyment
- Connection Eccentric coupling(s), Cover plate(s), Silencer(s)
- Diverter Turn operated diverter, Integrated into flow control handle
- Lever/Handle Temperature control handle, Flow control handle, Hot/Cold symbols, Easy-Grip surface, Eco feature for water flow
- Mechanical parts Ceramic head part for flow control, Thermostatic cartridge for automatic temperature control, Non-return valve(s), Litter filter(s)
- Number of spray functions 3 spray functions
- Shower parts Rotatable ball joint connection, Hand shower, Lockable in the middle position, MagShelf. Removable shelf with magnetic attachment, Adjustable shower rail bracket, Swivel overhead shower, Shower hose (1750 mm), Shower rail, Anti limescale technology (easy to clean), Twist guard for shower hose, Variable fixing points
- Shower spray Normal - Even and soft water stream, Massage - Strong water stream due to rotatable spray nozzles, Rain - Even and strong water stream
- Advanced features Flexible length / can be shortened, Anti-twist hose connector
- Color Matt black
- Temperature Safety stop against scalding at 38°C, The housing of the fittings conducts minimal heat
- Eco-flow at 3 bar 7.2 l/min
- Flow-rate at 3 bar 12/12 l/min
- Backflow prevention (EN1717) EB
- Connection size G3/4
- Hot water supply max. +80°C
- Installation width CC150± 15 mm
- Material Brass/Plastic
- Working pressure 1 - 10 bar
- EN standard EN1111
- Noise class I (ISO 3822)
SP6515920133 Shower system
Ask pricing from your local retailers.
| Spare parts | Code | Spare part guide | ||
| 01 |
|
Wall bracket (Matt black) |
|
|
| 02 |
|
Slide for shower rail (Matt black) |
|
|
| 03 |
|
Shelf (Matt black) |
|
|
| 04 |
|
Filter sealing, G3/4 |
|
|
| 05 |
|
Flow control handle (Matt black) |
|
Download |
| 06 |
|
Diverter |
|
Download |
| 07 |
|
Non-return valve, DN15 |
|
|
| 08 |
|
Thermostatic cartridge, 3.4 |
|
Download |
| 09 |
|
O-ring kit |
|
|
| 10 |
|
Temperature control handle (Matt black) |
|
Download |
