Features
- Diverter Turn operated diverter
- Concealed parts Rosette plate frame, Round rosette, BLUECLICK for an easy, screwless trim plate installation, BLUETUNE alignment after installation of +/- 3,5º, Fastening of the function unit with screws, Function unit
- Lever/Handle Single operating lever/handle, Pin shape, Hot/Cold symbols
- Mechanical parts ø 40 mm ceramic cartridge for flow and temperature control, Vacuum breaker
- Advanced features Inner body made of DZR brass
- Color Chrome
- Temperature Limitation option for maximum temperature and flow-rate, Adjustable hot water stop (included, retrofittable)
Flow attributes
- Flow-rate at 3 bar 20.4/20.4 l/min
Technical properties
- Hot water supply max. +80°C
- Material Brass
- Working pressure 0.5 - 10 bar
Regulations
- EN standard EN 817
- Noise class I (ISO 3822)
SP82603063 Cover part for bath and shower faucet
Ask pricing from your local retailers.
| Spare parts | Code | Spare part guide | ||
| 01 |
|
Lever (Chrome) |
|
|
| 01 |
|
Lever (Chrome) |
|
|
| 02 |
|
Symbol plug |
|
|
| 03 |
|
Cover sleeve (Chrome) |
|
|
| 04 |
|
Diverter knob (Chrome) |
|
|
| 04 |
|
Handle (Chrome) |
|
|
| 05 |
|
Cover flange, d 170 mm (Chrome) |
|
|
| 06 |
|
Diverter, 120° |
|
|
| 07 |
|
Functional unit |
|
|
