Features
- Aerator Standard aerator
- Connection Flexible inlet pipes
- Lever/Handle Hot/Cold symbols, Pin shape, Single operating lever/handle
- Mechanical parts ø 35 mm ceramic cartridge for flow and temperature control
- Advanced features Inner body made of DZR brass, Rapid installation system
- Spout Swivel spout, Swivel range limiting option
- Color Chrome
- Temperature Limitation option for maximum temperature and flow-rate, Adjustable hot water stop (included, retrofittable)
Flow attributes
- Flow-rate at 3 bar 12 l/min
Technical properties
- Backflow prevention (EN1717) AA
- Connection size G3/8
- DN-size (nominal dimension) DN15
- Hot water supply max. +80°C
- Material Brass
- Projection 164 mm
- Working pressure 0.5 - 10 bar
Regulations
- EN standard EN 817
- Noise class I (ISO 3822)
SP52202207 Kitchen faucet
Ask pricing from your local retailers.
| Spare parts | Code | Spare part guide | ||
| 1 |
|
Lever (Chrome) |
|
|
| 1.1 |
|
Screw, M5x8, SW2.5 |
|
|
| 1.3 |
|
Symbol plug (Grey) |
|
|
| 2 |
|
Covering cap, 33x3 mm (Chrome) |
|
|
| 3 |
|
Tightening nut, M40x1 |
|
|
| 4 |
|
Cartridge, 3.5 Classic |
|
Download |
| 4.1 |
|
Temperature adjustment limiter |
|
|
| 5.2 |
|
Supporting plate |
|
|
| 5.3 |
|
Bottom seal |
|
|
| 5.4 |
|
Fixing set |
|
|
| 5.5 |
|
Flexible pipe, L=550, G3/8-M8x1 |
|
|
| 5.6 |
|
Gasket, 9.5x14.4x2 |
|
|
| 5.7 |
|
Fixing screw, M8x1, L=140 |
|
|
| 6 |
|
Spout
Discontinued
|
|
|
| 6.1 |
|
Aerator, M24x1 STD HC A (Chrome) |
|
|
| 6.2 |
|
Fixing screw, M4x8 |
|
|
| 6.3 |
|
Sealing kit |
|
|
| 6.4 |
|
Cover plug (Chrome) |
|
|
| 6.5 |
|
Screw, M4x7 |
|
|
