Features
- Aerator PCA® - constant flow rate regardless of pressure variations
- Connection Flexible inlet pipes
- Extensions Pop-up waste with draw-rod
- Lever/Handle Hot/Cold symbols, Single operating lever/handle
- Mechanical parts ø 35 mm ceramic cartridge for flow and temperature control
- Advanced features Inner body made of DZR brass, Rapid installation system
- Spout Fixed spout
- Color Chrome
- Temperature Limitation option for maximum temperature and flow-rate, Adjustable hot water stop (included, retrofittable)
Flow attributes
- Flow-rate at 3 bar (with flow controller) 6 l/min
Technical properties
- Backflow prevention (EN1717) AA
- Connection size G3/8
- DN-size (nominal dimension) DN15
- Hot water supply max. +70°C
- Material Brass
- Projection 121 mm
- Working pressure 0.5 - 10 bar
Regulations
- EN standard EN 817
- Noise class I (ISO 3822)
Approvals and Declarations
- KIWA K6116/08
Sustainability
- EPD module A1 (kg CO2 eq.) 7,91
- EPD module A1-A3 (kg CO2 eq.) 9,04
- EPD module A2 (kg CO2 eq.) 0,38
- EPD module A3 (kg CO2 eq.) 0,75
- EPD module A4 (kg CO2 eq.) 0,25
- EPD module B7 (kg CO2 eq.) 1854,00
- EPD module C2 (kg CO2 eq.) 0,02
- EPD module C3 (kg CO2 eq.) 0,02
- EPD module C4 (kg CO2 eq.) 0,07
- EPD module D (kg CO2 eq.) -6,43
SP09092283 Washbasin faucet
Ask pricing from your local retailers.
