Features
- Aerator Hidden aerator
- Concealed parts Round rosette
- Lever/Handle Single operating lever/handle, Hot/Cold symbols, Pin shape
- Mounting holes 2 hole
- Advanced features Flexible length / can be shortened, Waterways without nickel coating
- Color Chrome
Flow attributes
- Flow-rate at 3 bar (with flow controller) 7.8 l/min
Technical properties
- Backflow prevention (EN1717) AA
- Hot water supply max. +80°C
- Material Brass
- Projection 235-300 mm
- Working pressure 0.5 - 10 bar
Regulations
- EN standard EN 817
- Noise class I (ISO 3822)
SP57932171 Cover part for washbasin faucet
Ask pricing from your local retailers.
| Spare parts | Code | Spare part guide | ||
| 1 |
|
Lever, 50 mm, d 7 mm (Chrome) |
|
|
| 1.1 |
|
Screw, M5x25, SW 2,5 |
|
|
| 1.4 |
|
O-ring, d 3x1.5 |
|
|
| 1.5 |
|
Protective cap (Chrome) |
|
|
| 2 |
|
Cover sleeve (Chrome) |
|
|
| 7 |
|
Cover flange, d 75 mm (Chrome) |
|
|
| 7.2 |
|
Cover flange, d 75 mm (Chrome) |
|
|
| 7.3 |
|
O-ring, 42x2 |
|
|
| 8 |
|
Spout, L=300 (Chrome) |
|
|
| 8 |
|
Spout, L=225 (Chrome) |
|
|
| 8.2 |
|
Connection nipple, M15x1,5xG1/2, SW 8 |
|
|
| 8.3 |
|
Aerator, CACHE M16.5x1 HC |
|
|
| 8.4 |
|
Key for aerator, M16.5x1 |
|
|
| N.I. |
|
Raising kit, 20 mm (Chrome) |
|
|
