Features
- Aerator Adjustable flow angle, Hidden aerator
- Concealed parts Round rosette, Sleeve
- Lever/Handle Single operating lever/handle, Hot/Cold symbols
- Spout Fixed spout
- Color Chrome
Flow attributes
- Flow-rate at 3 bar (with flow controller) 6 l/min
Technical properties
- DN-size (nominal dimension) DN15
- Hot water supply max. +80°C
- Material Brass
- Projection 193 mm
- Working pressure 0.5 - 10 bar
Regulations
- EN standard EN 817
SP57772103 Cover part for washbasin faucet
Ask pricing from your local retailers.
| Spare parts | Code | Spare part guide | ||
| 1 |
|
Lever (Chrome) |
|
|
| 1.1 |
|
Screw, M5x6, SW2.5 |
|
|
| 1.3 |
|
Cover plug (Chrome) |
|
|
| 2 |
|
Covering cap (Chrome) |
|
|
| 2.1 |
|
Cover sleeve (Chrome) |
|
|
| 3 |
|
Screw sleeve, M38x1 |
|
|
| 4 |
|
Cartridge, 3.5 Eco |
|
|
| 4 |
|
Cartridge, 3.5 Classic |
|
Download |
| 4.1 |
|
Temperature adjustment limiter
Discontinued
|
|
|
| 4.2 |
|
O-ring, d 28.24x2.62
Discontinued
|
|
|
| 4.4 |
|
O-ring, d 10.10x1.60
Discontinued
|
|
|
| 6.1 |
|
Gasket
Discontinued
|
|
|
| 7 |
|
Cover flange (Chrome) |
|
|
| 7.1 |
|
O-ring, d 46x2 |
|
|
| 8 |
|
Spout (Chrome) |
|
|
| 8.1 |
|
Fitting ring for aerator |
|
|
| 8.3 |
|
Aerator, M24x1 HC SSR-STD |
|
|
| 8.4 |
|
Key for aerator, SLIM AIR |
|
|
| 8.5 |
|
Threaded sleeve, G1/2 |
|
|
| 8.8 |
|
Extension screw kit, G1/2, SW12, 20 mm |
|
|
| 8.9 |
|
Extension screw kit, G1/2, SW12, 15 mm |
|
|
| 9 |
|
Installation box
Discontinued
|
|
|
| N.I. |
|
Angle piece |
|
|
| N.I. |
|
Raising kit, 20 mm (Chrome) |
|
|
| N.I. |
|
Key, SW30/34 |
|
|
_CatalogRender.webp "HANSABASIC, Cover part for washbasin faucet, 55602103")
