Features
- Aerator PCA® - constant flow rate regardless of pressure variations, Ball joint
- Connection Flexible inlet pipes
- Extensions Pop-up waste with draw-rod
- Lever/Handle Hot/Cold symbols, Single operating lever/handle
- Mechanical parts ø 35 mm ceramic cartridge for flow and temperature control
- Mounting holes 1 hole
- Advanced features Inner body made of DZR brass, Rapid installation system
- Color Chrome
- Temperature Limitation option for maximum temperature and flow-rate, Adjustable hot water stop (included, retrofittable)
Flow attributes
- Flow-rate at 3 bar (with flow controller) 6 l/min
Technical properties
- Connection size G3/8
- DN-size (nominal dimension) DN15
- Hot water supply max. +70°C
- Material Brass
- Projection 112 mm
- Working pressure 0.5 - 10 bar
Regulations
- EN standard EN 817
Sustainability
- EPD module A1 (kg CO2 eq.) 7,47
- EPD module A1-A3 (kg CO2 eq.) 8,54
- EPD module A2 (kg CO2 eq.) 0,36
- EPD module A3 (kg CO2 eq.) 0,71
- EPD module A4 (kg CO2 eq.) 0,24
- EPD module B7 (kg CO2 eq.) 1854,00
- EPD module C2 (kg CO2 eq.) 0,02
- EPD module C3 (kg CO2 eq.) 0,02
- EPD module C4 (kg CO2 eq.) 0,07
- EPD module D (kg CO2 eq.) -6,07
